import tensorflow as tf
from tensorflow.keras import layers
from tensorflow.keras.models import Model
from tensorflow.keras.callbacks import Callback, History
import tensorflow.keras.backend as K
from tensorflow.contrib.tpu.python.tpu import keras_support

from keras.datasets import cifar10 #from train1000 import cifar10

import numpy as np
import os, json, tarfile

# VGG-like model
def create_model():
    input = layers.Input((32, 32, 3))
    x = input
    for i in range(4):
        for j in range(3):
            x = layers.Conv2D(64*(2**i), 3, padding="same")(x)
            x = layers.BatchNormalization()(x)
            x = layers.Activation("relu")(x)
        if i != 3:
            x = layers.AveragePooling2D(2)(x)
    x = layers.GlobalAveragePooling2D()(x)
    x = layers.Dense(10, activation="softmax")(x)

    return Model(input, x)

def data_augmentation(image):
    outputs = np.zeros(image.shape, dtype=np.float32)
    # crop
    crop_x = np.random.randint(0, 4)
    crop_y = np.random.randint(0, 4)
    outputs[crop_x:crop_x+28, crop_y:crop_y+28, :] = image[crop_x:crop_x+28, crop_y:crop_y+28, :]
    # flip
    if np.random.rand() >= 0.5:
        outputs = outputs[:, ::-1, :]
    return outputs

def generator(X, y, batch_size, use_augmentation):
    while True:
        X_cache, y_cache = [], []
        indices = np.random.permutation(X.shape[0])
        for i in indices:
            if use_augmentation:
                X_cache.append(data_augmentation(X[i]))
            else:
                X_cache.append(X[i])
            y_cache.append(y[i])
            if(len(y_cache)==batch_size):
                X_batch = np.asarray(X_cache, np.float32)
                y_batch = np.asarray(y_cache, np.float32)
                X_cache, y_cache = [], []
                yield X_batch, y_batch

def train(use_aug):
    (X_train, y_train), (X_test, y_test) = cifar10.load_data() # cifar10()

    model = create_model()
    model.compile(tf.train.AdamOptimizer(1e-3), "categorical_crossentropy", ["acc"])

    tpu_grpc_url = "grpc://"+os.environ["COLAB_TPU_ADDR"]
    tpu_cluster_resolver = tf.contrib.cluster_resolver.TPUClusterResolver(tpu_grpc_url)
    strategy = keras_support.TPUDistributionStrategy(tpu_cluster_resolver)
    model = tf.contrib.tpu.keras_to_tpu_model(model, strategy=strategy)

    batch_size = 200
    hist = History()
    model.fit_generator(generator(X_train, y_train, batch_size, use_aug), steps_per_epoch=X_train.shape[0]//batch_size,
                        validation_data=generator(X_test, y_test, batch_size, False), validation_steps=X_test.shape[0]//batch_size,
                        max_queue_size=1, callbacks=[hist], epochs=200)
    history = hist.history
    print(max(history["val_acc"]))

    with open(f"softmax_aug_{use_aug}.json", "w") as fp:
        json.dump(history, fp)

if __name__ == "__main__":
    for aug in [False, True]:
        K.clear_session()
        print(aug, "starts")
        train(aug)

#################################################################


import tensorflow as tf
from tensorflow.keras import layers
from tensorflow.keras.models import Model
from tensorflow.keras.callbacks import Callback, History, LearningRateScheduler
import tensorflow.keras.backend as K
from tensorflow.contrib.tpu.python.tpu import keras_support

from keras.datasets import cifar10 #from train1000 import cifar10

import numpy as np
from sklearn.metrics import accuracy_score, euclidean_distances
import os, json, tarfile

# VGG-like model
def create_siamese(latent_dims):
    input = layers.Input((32, 32, 3))
    x = input
    for i in range(4):
        for j in range(3):
            x = layers.Conv2D(64*(2**i), 3, padding="same")(x)
            x = layers.BatchNormalization()(x)
            x = layers.Activation("relu")(x)
        if i != 3:
            x = layers.AveragePooling2D(2)(x)
    x = layers.GlobalAveragePooling2D()(x)
    if latent_dims != 512:
        x = layers.Dense(latent_dims)(x)

    return Model(input, x)

MARGIN = 0.25

#####################################################################################################
#####################################################################################################
#####################################################################################################
#####################################################################################################
# 上三角行列から対角成分を抜いた行列
def upper_triangle(matrix):
    upper = tf.matrix_band_part(matrix, 0, -1)
    diagonal = tf.matrix_band_part(matrix, 0, 0)
    diagonal_mask = tf.sign(tf.abs(tf.matrix_band_part(diagonal, 0, 0)))
    return upper * (1.0 - diagonal_mask)

#####################################################################################################
#####################################################################################################
#####################################################################################################
#####################################################################################################
def euclidean_triplet_loss(label, embeddings):
    # euclidean matrix
    x1 = tf.expand_dims(embeddings, axis=0)
    x2 = tf.expand_dims(embeddings, axis=1)
    euclidean = tf.reduce_sum((x1-x2)**2, axis=-1)

    # label equal matrix (* shape=[None, latent_dims])
    lb1 = tf.expand_dims(label[:, 0], axis=0)
    lb2 = tf.expand_dims(label[:, 0], axis=1)
    equal_mat = K.cast(tf.equal(lb1, lb2), "float32")

    # postives tf.whereが使えないので総当たりにする
    positive_flag = upper_triangle(equal_mat)
    # positive以外は0を入れる
    positive_dist = positive_flag*euclidean
    positive_dist = tf.reshape(positive_dist, [-1,1])

    # negatives
    negative_flag = upper_triangle(1.0-equal_mat)
    distance_max = tf.reduce_max(euclidean, keepdims=True)
    # negatives以外には(距離の最大値)を入れる
    negative_dist = negative_flag*euclidean + (1.0-negative_flag)*distance_max
    negative_dist = tf.reshape(negative_dist, [1,-1])

    # triplet loss
    loss = tf.maximum(positive_dist - negative_dist + MARGIN, 0.0)
    return tf.reduce_sum(loss)

#####################################################################################################
#####################################################################################################
#####################################################################################################
#####################################################################################################
class EmbeddingCallback(Callback):
    def __init__(self, siamese_model, X_train, y_train, X_test, y_test):
        self.model = siamese_model
        self.X_train = X_train
        self.y_train = y_train
        self.X_test = X_test
        self.y_test = y_test

        self.test_nearest_neighbor_acc = []
        self.test_threshold_simple = []
        self.test_threshold_weighted = []

    # スレッショルド使って推定
    def pairwise_distance_matrix(self, anchor_embedding, target_embedding):
        # メモリあふれるのでforループで計算
        distance = np.zeros((target_embedding.shape[0], anchor_embedding.shape[0]), dtype=np.float32)
        for i in range(distance.shape[0]):
            distance[i, :] = euclidean_distances(target_embedding[i,:].reshape(1,-1), anchor_embedding)[0]
        return distance

    # val_rate
    def true_accept(self, distance, labels, threshold):
        # uppper_mask
        upper_mask = np.triu(np.ones(distance.shape, dtype=np.bool), k=1)
        # true is same
        truth_same = np.expand_dims(labels, axis=1) == np.expand_dims(labels, axis=0)
        # pred same
        pred_same = distance <= threshold
        # true accept
        ta = np.logical_and(pred_same, truth_same)

        calc_true_same = np.logical_and(upper_mask, truth_same)
        calc_ta = np.logical_and(upper_mask, ta)
        # val rate
        return np.sum(calc_ta) / np.sum(calc_true_same)

    # accuracy
    def thresholded_acuracy(self, distance, labels, threshold):
        # uppper_mask
        upper_mask = np.triu(np.ones(distance.shape, dtype=np.bool), k=1)
        # true is same
        truth_same = np.expand_dims(labels, axis=1) == np.expand_dims(labels, axis=0)
        # pred same
        pred_same = distance <= threshold

        # true_positive
        true_positive = np.logical_and(truth_same, pred_same)
        # true_negative
        true_negative = np.logical_and(np.logical_not(truth_same), np.logical_not(pred_same))
        # accuracy
        accuracy_flag = np.logical_or(true_positive, true_negative)
        accuracy_flag = np.logical_and(accuracy_flag, upper_mask)
        return np.sum(accuracy_flag) / np.sum(upper_mask)

    # f1 score
    def thresholded_f1score(self, distance, labels, threshold):
        # uppper_mask
        upper_mask = np.triu(np.ones(distance.shape, dtype=np.bool), k=1)
        # true is same
        truth_same = np.expand_dims(labels, axis=1) == np.expand_dims(labels, axis=0)
        # pred same
        pred_same = distance <= threshold

        # tp, tn, fp, fn
        true_positive = np.logical_and(truth_same, pred_same)
        true_negative = np.logical_and(np.logical_not(truth_same), np.logical_not(pred_same))
        false_positive = np.logical_and(np.logical_not(truth_same), pred_same)
        false_negative = np.logical_and(truth_same, np.logical_not(pred_same))
        # uppermask -> num
        tp = np.sum(np.logical_and(upper_mask, true_positive))
        tn = np.sum(np.logical_and(upper_mask, true_negative))
        fp = np.sum(np.logical_and(upper_mask, false_positive))
        fn = np.sum(np.logical_and(upper_mask, false_negative))
        # f1 score
        precicion = tp / (tp + fp+ 1e-7)
        recall = tp / (tp + fn + 1e-7)
        f1 = 2 * recall * precicion / (precicion + recall + 1e-7)
        return f1

    def find_threshold(self, distance_matrix, onehots):
        assert distance_matrix.shape[0] == distance_matrix.shape[1]
        n = distance_matrix.shape[0]
        assert onehots.shape[0] == n
        labels = np.sum(np.arange(onehots.shape[1]) * onehots, axis=1).astype(np.int32)

        thresholds = np.arange(0.0, 4.0, 0.001, dtype=np.float32)
        rate = np.zeros(thresholds.shape, dtype=np.float32)
        for i, th in enumerate(thresholds):
            rate[i] = self.true_accept(distance_matrix, labels, th)
            #rate[i] = self.thresholded_acuracy(distance_matrix, labels, th)
            #rate[i] = self.thresholded_f1score(distance_matrix, labels, th)
        print("val_rate", rate)
        #print("accuracy", rate)
        #print("f1 score", rate)
        best_idx = np.argmax(rate)

        print(f"Best threshold : {thresholds[best_idx]}, Best VAL : {rate[best_idx]:.04}")
        #print(f"Best threshold : {thresholds[best_idx]}, Best accuracy : {rate[best_idx]:.04}")
        #print(f"Best threshold : {thresholds[best_idx]}, Best F1score : {rate[best_idx]:.04}")
        return thresholds[best_idx]

    # 最近傍を返す推定
    def one_nearest_neighbor(self, distance_matrix, anchor_onehots, target_onehots):
        assert distance_matrix.shape[0] == target_onehots.shape[0]
        assert distance_matrix.shape[1] == anchor_onehots.shape[0]

        indices = np.argsort(distance_matrix, axis=-1)
        # train の場合は正方行列
        if distance_matrix.shape[0] == distance_matrix.shape[1]:
            index = indices[:, 1]
        else:
            index = indices[:, 0]

        anchor_label = np.sum(np.arange(anchor_onehots.shape[1]).reshape(1,-1) * anchor_onehots, axis=-1)
        y_pred = anchor_label[index]
        y_true = np.sum(np.arange(target_onehots.shape[1]) * target_onehots, axis=-1)
        return accuracy_score(y_true, y_pred)

    # スレッショルドによる推定
    def thresholding_pred(self, distance_matrix, threshold, anchor_onehots, target_onehots, use_weighted):
        assert distance_matrix.shape[0] == target_onehots.shape[0]
        assert distance_matrix.shape[1] == anchor_onehots.shape[0]

        thresholded_distance = np.maximum(threshold-distance_matrix, 0.0)
        if not use_weighted:
            thresholded_distance = np.sign(thresholded_distance)
        y_pred = np.zeros(target_onehots.shape[0])
        print("thresholded num : ", np.mean(np.sum(np.logical_not(np.isclose(thresholded_distance,0.0)), axis=-1) ))
        for i in range(y_pred.shape[0]):
            score = thresholded_distance[i, :].reshape(-1,1) * anchor_onehots
            pred_index = np.argmax(np.sum(score, axis=0))
            y_pred[i] = pred_index
        y_true = np.sum(np.arange(target_onehots.shape[1]) * target_onehots, axis=-1)
        print(np.bincount(y_pred.astype(np.int32)))
        return accuracy_score(y_true, y_pred)

    def on_epoch_end(self, epoch, logs):
        train_embedding = self.model.predict(self.X_train)
        test_embedding = self.model.predict(self.X_test)

        # distance matrix
        distance_train = self.pairwise_distance_matrix(train_embedding, train_embedding)
        distance_test = self.pairwise_distance_matrix(train_embedding, test_embedding)

        # threshold
        print("")
        threshold = self.find_threshold(distance_train, self.y_train)

        # 最近傍推定
        print("Simple 1-Nearest Neighbor")
        train_acc = self.one_nearest_neighbor(distance_train, self.y_train, self.y_train)
        test_acc = self.one_nearest_neighbor(distance_test, self.y_train, self.y_test)
        self.test_nearest_neighbor_acc.append(test_acc)
        print(f"Train acc:{train_acc:.04}, Test acc:{test_acc:.04}, Best Test:{max(self.test_nearest_neighbor_acc):.04}")

        # スレッショルドによる推定
        print("Simple thresholding")
        train_acc = self.thresholding_pred(distance_train, threshold, self.y_train, self.y_train, False)
        test_acc = self.thresholding_pred(distance_test, threshold, self.y_train, self.y_test, False)
        self.test_threshold_simple.append(test_acc)
        print(f"Train acc:{train_acc:.04}, Test acc:{test_acc:.04}, Best Test:{max(self.test_threshold_simple):.04}")
        print("Weiged thresholding")
        train_acc = self.thresholding_pred(distance_train, threshold, self.y_train, self.y_train, True)
        test_acc = self.thresholding_pred(distance_test, threshold, self.y_train, self.y_test, True)
        self.test_threshold_weighted.append(test_acc)
        print(f"Train acc:{train_acc:.04}, Test acc:{test_acc:.04}, Best Test:{max(self.test_threshold_weighted):.04}")

#####################################################################################################
#####################################################################################################
#####################################################################################################
#####################################################################################################
def data_augmentation(image):
    outputs = np.zeros(image.shape, dtype=np.float32)
    # crop
    crop_x = np.random.randint(0, 4)
    crop_y = np.random.randint(0, 4)
    outputs[crop_x:crop_x+28, crop_y:crop_y+28, :] = image[crop_x:crop_x+28, crop_y:crop_y+28, :]
    # flip
    if np.random.rand() >= 0.5:
        outputs = outputs[:, ::-1, :]
    return outputs

#####################################################################################################
#####################################################################################################
#####################################################################################################
#####################################################################################################
def generator(X, y, batch_size, use_augmentation, n_latent_dims):
    while True:
        X_cache, y_cache = [], []
        indices = np.random.permutation(X.shape[0])
        for i in indices:
            if use_augmentation:
                X_cache.append(data_augmentation(X[i]))
            else:
                X_cache.append(X[i])
            y_item = np.zeros(n_latent_dims)
            y_item[0] = np.sum(np.arange(y.shape[1]) * y[i]) #1列目にラベルの数字を突っ込んでそれ以外はダミー
            y_cache.append(y_item)
            if(len(y_cache)==batch_size): #255で割ってあるから割らなくて良い
                X_batch = np.asarray(X_cache, np.float32)
                y_batch = np.asarray(y_cache, np.float32)
                X_cache, y_cache = [], []
                yield X_batch, y_batch

def step_decay(epoch):
    x = 1e-3
    if epoch >= 12: x = 2e-4
    if epoch >= 19: x = 4e-5
    return x

#####################################################################################################
#####################################################################################################
#####################################################################################################
#####################################################################################################
def train(n_dims, use_aug):
    (X_train, y_train), (X_test, y_test) = cifar10.load_data() # cifar10()
    siamese = create_siamese(n_dims)
    siamese.compile("adam", euclidean_triplet_loss)

    tpu_grpc_url = "grpc://"+os.environ["COLAB_TPU_ADDR"]
    tpu_cluster_resolver = tf.contrib.cluster_resolver.TPUClusterResolver(tpu_grpc_url)
    strategy = keras_support.TPUDistributionStrategy(tpu_cluster_resolver)
    siamese = tf.contrib.tpu.keras_to_tpu_model(siamese, strategy=strategy)

    embed_cb = EmbeddingCallback(siamese, X_train, y_train, X_test, y_test)
    hist = History()
    scheduler = LearningRateScheduler(step_decay)

    batch_size = 200
    siamese.fit_generator(generator(X_train, y_train, batch_size, use_aug, n_dims),
                          steps_per_epoch=X_train.shape[0]*400//batch_size, callbacks=[embed_cb, hist, scheduler],
                          max_queue_size=1, epochs=25)

if __name__ == "__main__":
    K.clear_session()
    print(512, "starts")
    train(512, False)














単身赴任日記3

  単身赴任生活が始まって約3か月。部屋の中は落ち着いて生活できるレベルになってきた。家電、家具で足らないものはない状況。ゴミ箱は寝室に1つしかないが、見た目気にしなければ写真の通り段ボールで十分。

f:id:Liq:20190303122414j:plain

  台所も不便なところはない。食器もこの程度で十分回る。

f:id:Liq:20190303122421j:plain


  リビングに入るとすぐ寝室が見えるのでパーティションを設置。1つは両面鏡にした。これで完璧な目隠しになっている。

f:id:Liq:20190303130353j:plain

  パーティションの裏側には、ちょっとしたハンガーラックを配置。服、鞄、買い物袋などの一時置き用に使っているがなかなか便利。

f:id:Liq:20190303130400j:plain

Passport 0

  はてな表記 というものがあるらしい。
  設定 - 基本設定 ー 編集モード において、「はてな記法モード 」を選択すればよい。ただし、「見たまま」で書かれた記事を編集する場合は、この「はてな記法モード 」にはならないようだ。選べるようにしてもらわないと。。

>|ruby|
class Foo
  def bar'baz' # return baz
  end
end
||<

Unix Alias

  Linux を使うようになってきた。ローカル環境で設定している alias コマンドを以下にまとめる。今後どこに環境を移そうがこれをベースに修正していければ。

###General
alias a 'alias'
alias am 'alias | more'
alias ccc 'echo Compile start ; cc -O \!*.c -o \!* -lm -lX11 && echo Compile end'
alias cd 'cd \!*; echo $cwd'
alias cl 'clear'
alias dir 'ls -laF'
alias dirm 'dir | less'
alias f 'finger'
alias fs 'finger XXXXXXXX'
alias h 'history'
alias ki2 'kinput2 &'
alias lo 'exit'
alias lsa 'ls -aF'
alias more 'less'
alias psa 'ps -aux'
alias psm 'ps -aux | less'
alias rm 'rm -i'
alias rmb 'rm *~'
alias rmbx 'rm .*~'
alias rmv 'rm -f .save*'
alias rmail '\xemacs -nw -f mh-rmail'
alias smail '\xemacs -nw -f mh-smail'
alias sc 'source .cshrc'
alias sjis 'nkf -bs \!* > \!*.sjis && rm \!*'
alias seus 'nkf -be \!* > \!*.seus && rm \!*'
alias uums 'uum -s -S'
alias yoko 'more /usr/local/squid/logs/access.log'

###Editor
alias emacs '\emacs -nw'
alias mule '\mule -nw'
alias xemacs '\xemacs -nw'
alias ed 'xemacs'

###Terminal
alias kt1 'kterm -km euc -n black -bg black -fg white &'
alias kt2 'kterm -km euc -n Oldlace -bg Oldlace -fg NavyBlue &'
alias kt3 'kterm -km euc -n AliceBlue -bg AliceBlue -fg NavyBlue &'
alias kt4 'kterm -km euc -n maroon -bg maroon -fg white &'
alias kt5 'kterm -km euc -n seashell2 -bg seashell2 &'
alias kt6 'kterm -km euc -n AntiqueWhite2 -bg AntiqueWhite2 &'

###Graphic
alias xs 'xsetroot -solid'
alias xb 'xsetroot -bitmap ~/img/\!*'
alias xbi 'xsetroot -bitmap /usr/X11R6/include/X11/bitmaps/\!*'
alias xvq 'xv -quit -root \!*'

晩御飯シリーズ

  一人暮らしで困ることの一つに"食事"がある。夕飯はほぼ毎日、弁当+α の状態。贅沢はしていないつもりだが、晩酌は欠かせない。。

栄養のバランスには気をつけているつもりだが。

f:id:Liq:20190223155721j:plain

カレーはレトルト

f:id:Liq:20190223155708j:plain

典型的な弁当

f:id:Liq:20190223155653j:plain

あっさりしたご飯にしたいと思ったら寿司にするときも。

f:id:Liq:20190223155641j:plain
